Direct replacement digital media receiver for select 1998 - 2013 Harley-Davidson® motorcycles. Features 3-inch full color, ultra-bright display with day/night modes and oversized buttons for easy control. Engineered for the ultimate in performance and sound quality featuring 4-Volt pre-amp outputs that don't clip! Plug and play installation with OEM electrical system requires no additional wiring or cutting of existing factory harnesses or components. Retains factory thumb controls. A Look at the PMX-HD9813 PMX-HD9813 H-D Road Glide Upgrade Installation
Plug and play installation requires factory wiring harness and connectors in order to retain functionality. Systems requiring rear speaker-line outputs will require additional harness (sold separately.) PMX source unit not compatible with factory amplified systems, CB, Intercom, rear volume controls, rear speakers on 1998-2005 Ultra’s, and factory equipped satellite radio systems. Estimated Installation Time: 1 HOUR.
Element Ready - Motorcycle Solutions
These models are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.
Made for iPod/iPhone
This device supports the Apple "Made for iPod/iPhone" protocol.
Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.
Bluetooth® Audio Streaming
Wirelessly stream audio to your unit with any compatible Bluetooth® device.
This source unit supports playback from a USB device.
This radio is ready to accept SiriusXM programming.
ASTM D4329 UV Certified
Marine Grade standards ensure resistance to extreme environments.
IPX6 Water Intrusion Rating
Water projected in powerful jets from any direction shall have no harmful effects.
IPX4 Water Intrusion Rating
Protects from splashing water, no matter the direction.
CISPR 25 Class 3 EMI Compliant
Vehicles, boats and internal combustion engines – Radio disturbance characteristics – Limits and methods of measurement for the protection of on-board receivers.
FCC, CE RED, IC, and RCM Certified
|Operating Voltage||9.5 - 16 VDC|
|Idle Current||< 2 Amps|
|Output Impedance||< 500 Ohms|
|Frequency Response||RCA: 20Hz - 20 kHz |
High-Level: 20Hz - 20 kHz
|THD+N||4-Ohms: < 1.0 %|
|RCA Output Voltage||Front: 4 V Max|
Rear: 4 V Max
Sub: 4 V Max
|Channel Separation||RCA: > 50 dB|
High-Level: > 50 dB
|Signal-to-Noise Ratio||RCA 2V: > 85 dB|
High Level (CEA-2006): > 75 dB
Max Wrms: > 80 dB
|AM Tuner||Range: 530 - 1710 kHz|
Sensitivity: 40 dB
Frequency Response: 45 to 2.4 kHz
|FM Tuner||Range: 87.9 - 107.9 MHz|
Sensitivity: 8 dB
Frequency Response: 20 - 15 kHz
|Supported Media Formats||MP3|
|USB Output Current||1.5A|
|USB Capacity||32 Gb max |
255 Folders max
999 Songs max
Format Win USB as FAT32
Format Mac USB as MS-DOS (FAT)
|Display Size:||Nominal Size: 3" Color TFT|
Resolution: 960 x 240
Brightness: 380 nits
Pixels: 320 x 240
View Angle: 120
|Made for iPhone Models||iPhone XS Max|
iPhone 8 Plus
iPhone 7 Plus
iPhone 6s Plus
iPhone 6 Plus
|Shipping Weight||4.75 Lbs. (2.15 Kg)|
|Made for iPod Models||iPod touch (5th generation)|
iPod touch (6th generation)
|Dimensions (HxWxD)||Faceplate: 2.7" x 8.4" x 0.7"|
(68.4 mm x 213 mm x 17.1 mm)
Chassis: 2.5" x 8.2" x 7.5"
(63.5 mm x 209.3 mm x 191 mm)
