Rockford Fosgate P300-8P

Rockford Fosgate Punch Series 8 Inch 300-Watt Powered Subwoofer - P300-8P



Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.


Our Price $509.99 CAD
Buy Online
Availability
Schedule Delivery

Literature

The Punch P300-8P is an "all in one" solution for dropping Bass in any factory or aftermarket system. This model features an 8" high output woofer with a 300-watt internal amplifier in a slim design enclosure that's great for truck and small car applications. The enclosure features quick release input and power connectors for easy removal when extra space is required.

Overview

The Punch 300-8P is a self-contained subwoofer enclosure with built-in amplifier. This "all in one" solution is great for systems that need extra Punch on the low-end of the frequency spectrum. The 8" high output subwoofer is impedance optimized for the built in 300-watt class-D amplifier that features a low-pass crossover, bass EQ and phase switch. The enclosure can be connected via speaker level inputs for connection to factory systems, or traditional line level inputs for aftermarket systems. It also features an intelligent auto turn-on/off circuit that eliminates the need for a separate turn-on wire. The enclosure itself is precision designed and constructed using MDF (Medium Density Fiberboard) for the best acoustical properties and covered with heat activated vinyl finish to resist marks.

  • High-Efficiency, Low Current Amplifier Design
  • Optimized 8" Low Impedance Woofer
  • 300 Watt Class-D Amplifier with Optimized "Closed Loop" Design
  • Adjustable 12db/Octave low pass crossover
  • On Board Phase Switch
  • Intelligent auto turn on/off function
  • Robust Power/Ground connections
  • Quick Input Connections for Easy Removal
  • On Board Adjustable Bass EQ
  • Remote bass level control included
  • Separate low level and speaker level inputs
  • Precision Constructed MDF Enclosure with Heat Activated Vinyl Finish
  • Thermal and over/under voltage protection
  • Slim Design For Truck Applications
  • 1 Year Warranty

Technologies

CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards.

CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Specifications
Frequency Response30 Hz to 200 Hz
Woofer Quantity1
Woofer Size8"
Woofer SeriesProprietary
Nominal Impedance
Power Handling (Watts RMS)300 Watts RMS
Enclosure TypeVented
Enclosure Material5/8" MDF (Medium Density Fiberboard
Speaker Connector
Integrated Amplifier300 Watts RMS
Crossover ControlsVariable 50 Hz to 200 Hz
12dB/Octave Butterworth
Tone ControlsBass Boost
0 dB to +12 dB;
Phase Control0° to 180°
Remote ControlPunch Level Control (Included)
Replacement Part: 1510-57864-01
Auto Turn-On SelectorRemote Trigger
DC Offset Sense
Audio Sense
Input SwitchHigh-Level (Speaker Line)
Low-Level (RCA)
Signal InputLow/High-Level: 1 RCA Pair (L/R Summed)
Replacement Part: 1560-57865-01
Input SensitivityLow-Level: 150 mV to 6 V
High-Level: 300 mV to 12 V
Input Impedance20k Ohms
Power Input ConnectorQuick Disconnect
Replacement Part: 1040-57860-01
Power Wire GaugeB+/GND: 8 AWG
REM: 18 AWG
Circuit Topology ClassClass-D
Heatsink TypeExtruded Aluminum
CoolingConvection
Visual IndicatorsPower/Protect LED
Fuses20 Amp (2 x 10 Amp ATO Fuse)
Dimensions Box H x W x D Wedge H x W x D1 x D211.4" x 17.6" x 5.6"
289 mm x 448 mm 141 mm
Shipping Weight19 lbs. (8.6 kg)
