Rockford Fosgate Universal Bluetooth Receiver To RCA For Wireless Streaming - RFBTRCA
You may also like
The RFBTRCA is a universal Bluetooth receiver for wireless audio streaming and features RCA outputs for easy connection to an audio system.
Overview
The RFBTRCA universal Bluetooth™ adapter allows to wirelessly stream media (music library, Pandora, Rhapsody, etc) from a Bluetooth™ enabled device through stereo RCA output jacks. Auxiliary input powered by the vehicle’s 12V accessory socket. Easy 1-button pairing function binds to Bluetooth™ enabled device and chimes on subsequent connections. Supplied 1/8” (3mm) cable sends audio through RCA outputs directly feeding audio system. Compatible with most Bluetooth™ devices, including smartphones, tablets, and laptops.
- Simple one button pairing
- Bluetooth™ streaming receiver
- Bluetooth™ V3.0+EDR
- 12VDC wired connection
- 1/8" (3.5mm) to stereo RCA audio output
- Compatible with Apple & Android Bluetooth™ devices
- Auto connect after initial pairing
- 3 ft. (1m) 1/8" (3.5mm) to male RCA audio cable included
- Class 2 output power
- 33 foot range
- 1 Year Warranty
Technologies
Bluetooth™ Audio Streaming
Wirelessly stream audio to your unit with any compatible Bluetooth™ device.
| Specifications | |
|---|---|
| Output Voltage | 800 mV |
| Output Impedance | — |
| Input Impedance | — |
| Frequency Response | 20 Hz - 20 kHz |
| Operating Voltage | 9-16 VDC 8" long coaxial power -to- bare wire +/- Connector Type C: 3.8 mm OD, 1.4 mm ID |
| Shipping Weight | 0.28 Lbs. (0.127 Kg.) |
| Dimensions (H x W x D) | 0.51" x 1.90" x 1.95" (13 mm x 48 mm x 49 mm) |
| Mounting | Dash/Surface Mount |
| Processor Type | Streaming Device |
| Signal Processing | Bluetooth™ Profile: V3.0 + EDR |
| THD+N | <1.0 |
| Signal-to-Noise | >90 dB (DAC) >80 dB (Max Output) |
| Signal Output | 2-ch audio 3 ft. (1m) long output cable 1/8" (3.5mm) stereo -to- L/R male RCA |
| Signal Input | Wireless Bluetooth |
| LED Indicators | Power: Center Solid Blue Pairing: Left/Right Blinking Blue Connected: All Solid Blue |
