The AT-LPW40WN is a fully manual, belt-drive turntable designed to give you optimal high-fidelity audio reproduction from vinyl. It features an aesthetically pleasing anti-resonance MDF (medium density fiberboard) plinth with simulated walnut wood veneer to limit low-frequency acoustical feedback and a sensor-monitored motor to ensure accurate platter rotation speeds at 33-1/3 and 45 RPM.
The turntable includes a straight carbon-fiber tonearm with adjustable tracking force and an AT-HS4 universal ½"-mount headshell with an AT-VM95E Dual Moving Magnet phono cartridge. Audio-Technica has been a leader in phono cartridge design for more than 50 years, and that expertise shows in the versatile, high-performance AT-VM95E cartridge, which comes with a 0.3 x 0.7 mil elliptical stylus, but is also compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application.
The AT-LPW40WN is equipped with a built-in selectable phono preamp and a detachable dual RCA output cable to enable direct connection to components with or without a dedicated phono input.
The LPW40WN was designed to give you optimal high-fidelity audio reproduction with smart styling.
Plays 33-1/3 and 45 RPM Records with Speed Control
Built-in Switchable Phono Pre-amplifier
Straight Carbon-fiber Tonearm
AT-VM95E Dual Magnet™ Phono Cartridge
Optimal High-fidelity Audio Reproduction
Stylish Wood Turntable
A stunning addition to any system, the AT-LPW40WN features an anti-resonance plinth with simulated walnut wood veneer to limit low-frequency acoustic feedback.
|Type||Belt-drive manual turntable|
|Motor||DC servo with Active Speed Stabilization|
|Drive Method||Belt drive|
|Speeds||33-1/3 RPM, 45 RPM|
|Turntable Platter||Die-cast aluminum|
|Wow and Flutter||< 0.15% WRMS (33 RPM) at 3 kHz|
|Output Level||Pre-amp “PHONO”: 4.0 mV nominal at 1 kHz, 5 cm/sec , Pre-amp “LINE”: 200 mV nominal at 1 kHz, 5 cm/sec|
|Phono Pre-Amp Gain||35 dB nominal, RIAA equalized|
|Power Supply Requirements||100-240 V, 50/60 Hz, 0.5 A Max.|
|Dimensions||420.0 mm (16.53") W x 340.0 mm (13.38") D x 116.9 mm (4.6") H|
|Weight||4.72 kg (10.40 lbs.) without dust cover|
|Accessories Included||Dust cover, Platter, Turntable mat, Drive belt, Counterweight, AT-HS4 headshell, AT-VM95E stereo cartridge, 45-RPM adapter, RCA audio cable (approx. 1.0 m (3.3')), AC adapter (approx. 1.5 m (4.9')) (AD-SA1205WE), Dust cover hinges|
|Notes||Tonearm type: Static balanced straight carbon tonearm , Effective arm length: 223.6 mm , Overhang: 18.6 mm , Tracking error angle: <2 degrees , Applicable cartridge weight: 12-17 g , Stylus pressure adjustment range: 0-3 g , AC Adapter: 12 V, 0.5 A , Replacement Stylus: AT-VMN95E|
