Audison 8 Channel DSP Signal Interface Processor - BITONE.1

Despite its compact size, the bit One is equipped with a powerful 266 MHz / 32 bit floating point DSP microprocessor, working in real time on all the functions of the most complete systems. Managed and configured by a simple and intuitive computer software, it is possible to make adjustments to improve the signal through each phase of its path; from input to output.Eight input channels for four different signal typologies (amplified, pre-amplified, coaxial electric and TOSLINK optical digital) and six different sources managed through a remote control, making the bit One a unique interface suitable for any need.Eight analog and/or digital output channels ensure a wide expandability for any audio system configuration

Features

Audio DSP and converters

32-BIT floating point Analog Devices Sharc (Clock speed: 266MHz) Digital Signal Processing chip and Wolfson A/D D/A converters working in PCM at 48kHz with 24 Bit resolution.

Tuning functions can be heard in real time due to processing speed.

Audio Inputs

8 independent high-level channels (with automatic summing capability) or 6 independent analog low-level channels;

2 analog low-level stereo auxiliary inputs;

1 optical digital input;

1 electric coaxial digital input;

1 high-level momentary audio interrupt input (with Mute IN) for use with mobile phone or navigation systems.

Audio Outputs

8 independent low-level analog channels featuring adjustable level and 1 AD Link output

(8 independent digital audio channels through a single CAT 5.S LAN cable for use with AD Link provided amplifiers).

Digital Control System

1 USB /B (2.0) connector for PC connection;

2 AC Link control bus connectors for DRC and AC Link amplifiers.

Configuration

Guided procedure that, thanks to a wide range of set names, provides the ability to assign each component to the bit One connections and automatically coordinate their functioning.

Turn-on Controls

ART automatic remote turn on/off circuit;

Through the car ignition key with memory function;

Through the DRC;

Automatically through the hands-free phone kit.

In/Out Volume

Input sensitivity automatically adjusted for the main inputs (with supplied Test CD and DVD);

Manual input sensitivity adjustment for auxiliary inputs;

Independent level control for each output channel for system fine tuning (-40 ÷ 0 dB).

Dynamic Equalizer

System automatically self-adjusts through an equalization between low and high listening levels that can be set by the user and controlled by the DRC.

De-equalization and calibration

Automatic de-equalization of signal fed into the high-level inputs (with supplied Test CD or DVD) and levels calibration.

Equalizers

One 31-band graphic equalizer (1/3Oct.; ±12dB) for each one of the 4 auxiliary input;

One 31-band graphic equalizer (1/3 Oct.; ±12dB) for each one of the 8 output channels.

Crossover Filter

Filter typology: Selectable; Hi-pass, Lo-pass, Bandpass, Full Range;

Cut-off frequency: 70 steps available from 10 Hz to 20 kHz;

Cut-off slope: Selectable; 6 to 48 dB/Oct.;

Alignments: Selectable; Linkwitz or Butterworth;

Mute: Selectable for each output (On/Off);

Phase: Selectable for each output (0°/180°)

Signal channels reconstruction

It can reconstruct a stereo signal from a multi-channel signal. In addition it can reconstruct a centre channel and subwoofer channels from a stereo input alone.

Time Alignment

Guided procedure for the speaker distance data entry with an automated calculation of proper delay times for each channel for accurate time alignment set-up.

System also provides for manual fine tuning of delay (0 ÷ 22 ms max).

Auto Restart Automatic turn Off/On, if the DSP locks up.

DRC Master Volume control, Subwoofer Volume control, Balance control, Fader control, Input selection, Memory selection, Dynamic Equalizer On/Off, Adjustable display brightness, Access to digital features of Audison TH amps if connected.

Memory

4 presets separately managed and recalled by the DRC Remote Control.

Bit One software

Windows (Win 2000, XP, Vista, 7) based software with “Standard” and “Expert” operating modes;

Screen resolution: 1024 x 768 px min.

TECHNOLOGIES

ANALOG DEVICE SHARC™ DSP

Analog Device SHARC™ series chip with floating point precision, to reach the highest audio quality.

BIT DRIVE

Auto tuning by Audison bit Tune and communication with bit Drive portal.

DE-EQ

De-equalization function to “flatten” any equalization applied by default by OEM sources.

Full DA

Pure digital signal transfer with a resolution up to 24 bit / 48 kHz
