Born from Audison unique know-how within the industry, bit nove is the perfect tool to expand a car audio system maximizing its performance. The advanced PC software sums up the channels belonging to the same front and de-equalizes the OEM source frequency response in a few simple steps. For each channel, the powerful DSP provides a 10-pole parametric equalizer allowing for optimal adjustments, a 68 steps frequency crossover, Butterworth or Linkwitz-Riley type filters with slopes from 6 to 24 dB/Oct, and a time-delay line.
FEATURES
- iDatalink Maestro AR compatibility
- 6 high (3 ÷ 20V) and low (1.2 ÷ 8V) level inputs
- output channels on RCA connectors
- Built-in USS “ Universal Speakers Simulator
- Auxiliary RCA input (0.3 ÷ 5V)
- Two optical digital inputs with a maximum accepted resolution of 192 kHz/24 bit
TECHNOLOGIES
iDatalink Maestro AR compatibility
When bit Nove is installed into a compatible vehicle using the iDatalink Maestro AR (sold separately), the user can enjoy a perfect integration with factory installed navigation, advanced safety systems, voice-controlled hands-free and infotainment.
USS technology
USS technology allows bit processors to work with headunits featuring the “speaker load detection” circuit
BIT DRIVE
Auto tuning by Audison bit Tune and communication with bit Drive portal.
DE-EQ
De-equalization function to “flatten” any equalization applied by default by OEM sources.
Full DA
Pure digital signal transfer with a resolution up to 24 bit / 48 kHz
| AMPLIFIER TECH DATA | |
|---|---|
| Channels | 9 |
| Sample Rate | 24 bit / 48 kHz |
| Hi Level Inputs | 6 |
| Low Level Inputs | 6 |
| Digital Inputs | 2 |
| Processing Method | Fixed point |
| Idling current | 0.53 A |
| Switched off without DRC MP | 1 mA |
| Switched off with DRC MP | 4.5 mA |
| Remote IN | 4 ÷ 15 VDC (1mA) |
| Remote OUT | 10 ÷ 15 VDC (130 mA) |
| SIGNAL STAGE | |
| Distortion - THD @ 1 kHz, 1 VRMS Output | 0.005% |
| Bandwidth @ -3 dB | 10 Hz ÷ 22 kHz |
| S/N ratio @ A weighted, 4 V Output, 2 V MASTER input | 102 dBA |
| S/N ratio @ A weighted, 4 V Output, 2 V AUX input | 110 dBA |
| S/N ratio @ A weighted, 4 V Output, OPTICAL IN1/IN2 input | 101.5 dBA |
| Channel Separation @ 1 kHz | 85 dBA |
| Input sensitivity PRE IN / Master | 1.2 ÷ 8 VRMS |
| Input sensitivity Speaker IN / Master | 3 ÷ 20 VRMS |
| Input sensitivity AUX | 0.3 ÷ 5 VRMS |
| Input impedance Pre In | 15 kΩ |
| Input impedance Speaker In / AUX | 12 Ω |
| Max Output Level 0.1% THD | 4 V |
| INPUT STAGE | |
| Low level (Pre) | Ch1 ÷ Ch6; AUX L/R |
| High Level (Speaker In) | Ch1 ÷ Ch6 |
| Digital | 2 x Optical S/PDIF; Max 192 kHz / 24 bit |
| OUTPUT STAGE | |
| Low level (Pre) | Ch1 ÷ Ch9 |
| Connection | |
| From / To Personal Computer | 1 x Micro USB |
| To Audison Amplifiers | 1 x AC Link |
| To Audison DRC MP | 1 x AC Link |
| CROSSOVER | |
| Filter type | Full / Hi pass / Low Pass / Band Pass |
| Filter mode and slope | Linkwitz @ 12/24 dB - Butterworth @ 6/12/18/24 dB |
| Crossover Frequency | 68 steps @ 20 ÷ 20k Hz |
| Phase control | 0° / 180° |
| TIME ALIGNMENT | |
| Distance | 0 ÷ 510 cm / 0 ÷ 200.8 inches |
| Delay | 0 ÷ 15 ms |
| Step | 0,08 ms; 2,8 cm / 1.1 inch |
| GENERAL REQUIREMENTS | |
| PC connections | USB 1.1 / 2.0 / 3.0 Compatible |
| PC OS | Microsoft Windows (32/64 bit): Vista, Windows 7, Windows 8, Windows 10 |
| Video Resolution with screen resize | min. 1024 x 600 |
| Ambient operating temperature range | 0 °C to 55 °C (32 °F to 131 °F) |
