JBL 3.1 Channel Soundbar with a Built-in Subwoofer - JBLSB510BLKAM

Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Our Price $229.98 CAD
Schedule Delivery


  • Dedicated center channel provides superior voice clarity
  • Built-in subwoofer
  • One cable connection with HDMI ARC
  • Wireless music streaming via
  • Bluetooth
  • Dolby Audio embedded

The JBL Cinema SB510 is a 3.1 channel all-in-one soundbar with a builtin subwoofer. It delivers 200 watts of powerful Dolby Audio with deep bass, all in a hassle-free, compact design that fits neatly into any room.

A dedicated center channel driver means TV and film dialogue is always crystal clear. Setup is easy using either one cable HDMI ARC or optical connections, and convenient Bluetooth connectivity means you can use it for wireless music streaming from any device.

Features and Benefits
Dedicated center channel provides superior voice clarity

A dedicated center channel delivers film and TV dialogue with amazing clarity. You’ll never ask “What did they just say?” again.

Built-in subwoofer
The built-in subwoofer delivers deep bass without the need for another box or extra cables to clutter up your space.

One cable connection with HDMI ARC
The one cable HDMI ARC connection allows for the simplest setup and a hassle-free user experience.

Wireless music streaming via Bluetooth
Stream and enjoy all your music wirelessly from any mobile device.

Dolby Audio embedded
Delivers powerful sound that enhances any movie experience.

General Specifications
Subwoofer transducer: 1x (70 x 88)mm, built-in subwoofer
Soundbar transducer: 3x (45 x 80)mm racetrack drivers
Subwoofer output power (Max. @THD 1%): 50W
Soundbar output power (Max @THD 1%): 150W
Total speaker power output (Max @THD 1%): 200W
Power supply: 100 - 240V AC, ~ 50/60Hz
Sound system: 3.1 channel
Model: CINEMA SB510
Wireless Specification
Bluetooth Max. transmitting power: <10 dBm (EIRP)
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth profile: A2DP 1.3, AVRCP 1.6
Bluetooth version: 5.3
USB Specification
MP3 bitrate: MPEG 1 Layer 1: 32 kbps - 448 kbps;
MPEG 1 Layer 2: 32 kbps - 384 kbps; MPEG 1 Layer
3: 32 kbps - 320 kbps; MPEG 2/2.5 Layer 1: 32 kbps
-256 kbps; MPEG 2/2.5 Layer 2/3: 8 kbps - 160 kbps
Wireless Specification
Bluetooth modulation: GFSK, π/4 DQPSK, 8DPSK
Packaging Weight: 5.0kg / 11.0 lbs
Packaging dimensions (W x H x D): 1112 x 116 x 164mm / 43.8’’ x 4.6’’ x 6.5’’
Soundbar weight: 3.5kg / 7.7 lbs
Soundbar dimensions (W x H x D): 950 x 67 x 105mm / 37.4’’ x 2.6’’ x 4.1’’
USB Specification
MP3 sampling rate: 16 - 48 kHz
MP3 codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
Supporting file formats: mp3
USB rating: 5V DC, 0.5A
USB port: Type A
Audio Specification
Audio inputs: 1 Optical, Bluetooth and USB (USB playback is available in US version. For other versions, USB is for Service only.)
Frequency response: 55Hz-20kHz (-10dB)
HDMI Specification
HDMI HDCP version: 1.4
HDMI ARC (Audio Return Channel): 1
General Specifications
Standby power: < 0.5W
Operating temperature: 0°C - 45 °C
