| Our Price | $229.98 CAD |
Features
The JBL Cinema SB510 is a 3.1 channel all-in-one soundbar with a builtin subwoofer. It delivers 200 watts of powerful Dolby Audio with deep bass, all in a hassle-free, compact design that fits neatly into any room.
A dedicated center channel driver means TV and film dialogue is always crystal clear. Setup is easy using either one cable HDMI ARC or optical connections, and convenient Bluetooth connectivity means you can use it for wireless music streaming from any device.
Features and Benefits
Dedicated center channel provides superior voice clarity
A dedicated center channel delivers film and TV dialogue with amazing clarity. You’ll never ask “What did they just say?” again.
Built-in subwoofer
The built-in subwoofer delivers deep bass without the need for another box or extra cables to clutter up your space.
One cable connection with HDMI ARC
The one cable HDMI ARC connection allows for the simplest setup and a hassle-free user experience.
Wireless music streaming via Bluetooth
Stream and enjoy all your music wirelessly from any mobile device.
Dolby Audio embedded
Delivers powerful sound that enhances any movie experience.
| General Specifications | |
|---|---|
| Subwoofer transducer: | 1x (70 x 88)mm, built-in subwoofer |
| Soundbar transducer: | 3x (45 x 80)mm racetrack drivers |
| Subwoofer output power (Max. @THD 1%): | 50W |
| Soundbar output power (Max @THD 1%): | 150W |
| Total speaker power output (Max @THD 1%): | 200W |
| Power supply: | 100 - 240V AC, ~ 50/60Hz |
| Sound system: | 3.1 channel |
| Model: | CINEMA SB510 |
| Wireless Specification | |
| Bluetooth Max. transmitting power: | <10 dBm (EIRP) |
| Bluetooth transmitter frequency range: | 2400 MHz – 2483.5 MHz |
| Bluetooth profile: | A2DP 1.3, AVRCP 1.6 |
| Bluetooth version: | 5.3 |
| USB Specification | |
| MP3 bitrate: | MPEG 1 Layer 1: 32 kbps - 448 kbps;
MPEG 1 Layer 2: 32 kbps - 384 kbps; MPEG 1 Layer 3: 32 kbps - 320 kbps; MPEG 2/2.5 Layer 1: 32 kbps -256 kbps; MPEG 2/2.5 Layer 2/3: 8 kbps - 160 kbps |
| Wireless Specification | |
| Bluetooth modulation: | GFSK, π/4 DQPSK, 8DPSK |
| Dimensions | |
| Packaging Weight: | 5.0kg / 11.0 lbs |
| Packaging dimensions (W x H x D): | 1112 x 116 x 164mm / 43.8’’ x 4.6’’ x 6.5’’ |
| Soundbar weight: | 3.5kg / 7.7 lbs |
| Soundbar dimensions (W x H x D): | 950 x 67 x 105mm / 37.4’’ x 2.6’’ x 4.1’’ |
| USB Specification | |
| MP3 sampling rate: | 16 - 48 kHz |
| MP3 codec: | MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3 |
| Supporting file formats: | mp3 |
| USB rating: | 5V DC, 0.5A |
| USB port: | Type A |
| Audio Specification | |
| Audio inputs: | 1 Optical, Bluetooth and USB (USB playback is available in US version. For other versions, USB is for Service only.) |
| Frequency response: | 55Hz-20kHz (-10dB) |
| HDMI Specification | |
| HDMI HDCP version: | 1.4 |
| HDMI ARC (Audio Return Channel): | 1 |
| General Specifications | |
| Standby power: | < 0.5W |
| Operating temperature: | 0°C - 45 °C |
