Product Overview
Smooth waveforms
Loss of smoothness
Fine waveforms
Rich and Immersive High-Resolution Audio
High-Resolution Audio is high-quality sound that exceeds CD standard. High-resolution audio captures and beautifully expresses all the details of your favorite music. Through ultra-high and low frequencies, immerse yourself in a rich and high-quality sonic experience.
Output Coil with Magnetic Shield
Prevents magnetic flux from radiating from the subwoofer's coil, resulting in reduced noise and enhanced sound quality.
Conformal Coating
Improved moisture resistance of the circuit boards to prevent corrosion.
Protective Caps and Cover
All control holes,RCA, wired remote and Speaker Level input terminals are coverd with caps and plastic covers to avoid from moisture and dust.
Sliding Terminal Cover
Detachable sliding terminal cover offers a sleek design and easier installation.
One-side Connection
All terminals and connections are on one side for easier installation and a cleaner look.
Variable Gain Circuit
Improved Signal to Noise Ratio
Speaker Level Input Harness
Speaker Level Input Harness is included to connect to speaker wires from factory installed receivers.
Optional Wired Level Control Ready
The optional KCA-RC01A wired remote level control allows you to easily adjust the subwoofer volume.
*Control unit does not support conformal coarting or water-proof.
Key Features
General | |
---|---|
Current Consumption | 42[A] |
Operating Voltage | 14.4V(11-16V allowable) |
Terminals | |
Speaker Output | M4 Screw Type Terminal Block |
Battery & Ground | M6 Screw Type Terminal Block |
AUDIO SECTION | |
Speaker Level Input Sensitivity | 4.0[V] - 12.0 [V] |
RCA Input Sensitivity | 0.2[V] - 5.0 [V] |
Infrasonic Filter | - |
Bass Boost | 40Hz, 0dB - +18dB (SUB) |
High-Pass Filter | 50Hz-200Hz, -12dB/oct (A/B) |
Specifications | |
Frequency Response | 20Hz-200Hz (+0dB, -3dB) SUB |
Input Impedance | 10k ohm |
Speaker Impedance | 4Ω (2Ω to 8Ω allowable) |
Bridged Connection | 4Ω to 8Ω allowable |
AUDIO SECTION | |
Low-Pass Filter | 50Hz-200Hz, -24dB/oct (SUB) |
Specifications | |
Frequency Response | 20Hz-50kHz (+0dB, -3dB) A/B |
Signal to Noise Ratio | 100dB (Reference: Rated Power into 4Ohms at 14.4V) |
Rated Power Output at 14.4V | |
A/B (Bridged 4Ohms) | 150Watts RMS x 2 (Bridged 4 Ohms, 1kHz, ≤1.0% THD) |
SUB (2 Ohms) | 500Watts RMS x 1 (2 Ohms, 100Hz, ≤0.5% THD) |
SUB (4 Ohms) | 300Watts RMS x 1 (4 Ohms, 20-200Hz, ≤0.5% THD) |
A/B (2 Ohms) | 75Watts RMS x 4 (2 Ohms, 1kHz, ≤1.0% THD) |
A/B (4 Ohms) | 50Watts RMS x 4 (4 Ohms, 20-20kHz, ≤1.0% THD) |
Maximum Power Output | |
MAX POWER | 1600W |
CTA-2006 Primary Ratings | |
Signal-to-Noise Ratio | 80dBA (Reference: 1Watt into 4Ohms) |
Power Output | 50 Watts RMS x 4 + 300 Watts RMS x 1 at 4 Ohms and ≤1%THD+N |
General | |
Dimensions(WxHxD) | (W)9-3/4" x (H) 2-1/16” x (D)6-5/8” |
Dimensions(WxHxD) | (W) 248mm x (H) 53mm x (D) 169mm |
Weight | 4.6 lbs ( 2.1 kg) |
