Kenwood KMR-XM500

Kenwood Digital Media Receiver with Bluetooth - KMR-XM500

Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Our Price $648.00 CAD
Sale Ends : February 28, 2025
On Sale
Schedule Delivery


  • 3” Gauge-Style Mounting
  • 2.7” LCD Display
  • AM/FM/Global Weather Band Tuner
  • Waterproof Rating of IP66
  • Wired Remote Ready (KCA-RC35MR, Sold Separately)
  • SiriusXM Ready®
  • Rear USB Port w/ 1.5A Charging
  • Variable Color Illumination
  • Bluetooth® Streaming
  • Rear View Camera Input
  • 50 Watts x 4
  • 3 Pre-Outs (5.0V)


2.7 Color TFT

LCD display secures higher visibility under sunlight and day-time use.

Variable Color Illumination

Bright variable color LEDs can be adjusted to match any color of lighting.


FLAC Supported

Compatible with various audio file formats from FLAC and, to MP3, WMA and AAC.

Graphic EQ

13-Band equalizer gives optimal tuning enhancements.


Global tuner

Worldwide access to local radio stations.

Conformal Coating

Improved moisture resistance of the circuit boards to prevent corrosion.


3" Hole Installation

Provides more flexibility in mounting applications and locations.

Rear USB

Enables easy placement and access of the USB input.


Rear View Camera Input

An optional rear view camera enhances safety while backing up and monitoring behind your UTV, boat, etc..


Enhanced Durability

Water-proof & Dust-proof Front Panel

IP66 certified


Salt Spray-Proof

ASTM B117 salt spray (or salt fog) corrosion test simulates harsh conditions in a salt water environment to ensure the product does not corrode or fail in these harsh conditions.


UV Protection

The unit cover satisfied ASTM D4329 UV resistant test.


Vibration Resitant

3-axis multi-freqeuncy vibration tested to withstand damaging shocks.


Conformal Coating

Improved moisture resistance of the circuit boards to prevent corrosion.



The Best Audio Experience


Streaming Music

Listen to popular music applications and music stored on your device with basic audio controls.


Playable USB Files

Compatible with a broad range of audio file formats from FLAC and MP3, WMA and AAC.


13-Band EQ

13-Band equalizer gives optimal tuning enhancements for the listener.


Independent Subwoofer Volume Control

allows you to easily adjust your subwoofer volume.

*The volume works when the SW RCA Output is connected to amplifier/Subwoofer.


All Weather System EXPANSION Ready

The KMR-XM500 has RCA outputs to expand the system to connect amplifiers to power additional speakers & subwoofer(s).


Additional Features


2.7" LCD Display

2.7" LCD display secures higher visibility under sunlight and daytime use.


Rear View Camera Input Support

KMR-XM500 is equipped with a rear view camera input. With an optional camera connected, you have increased safety while driving UTVs, boats, etc..


SiriusXM Radio Ready

Access additional music, sports and entertainment content on the go with SiriusXM Radio. (Optional SiriusXM tuner required, sold separately)


AM/FM/Global Weather Band Tuner

KMR-XM500 supports AM/FM and Global weather band.


Multicolor Illumination Controls

Bright variable color LED's can be adjusted to match your environment.


Spanish Text Display

On-screen display menu now available in Spanish.



The KCA-RC35MR (Sold Separately) is designed to control the KMR-XM500 from multiple positions.

The remote controls multi-functions such as volume, source, & track from a compact size.



You can connect up to 6 remotes in-line with each other.

Full Bandwidth Power19W x 4 ( 4 ohm, RMS), 28W x 4 ( 2 ohm, RMS)
Maximum Power34W x 4 ( 4 ohm, Peak), 50W x 4 ( 2 ohm, Peak)
ProfileAVRCP 1.5(Audio/Video Remote Control Profile)
ProfileA2DP(Advanced Audio Distribution Profile)
PairingSSP(Secure Simple Pairing)
Maximaum Communication rangeLine of sight approx.10m(32.8ft)
RF Output Power0dBm(AVE), Power Class 2
Frequency Range2.4GHz - 2.4835GHz
VersionBluetooth 5.0
Speaker Impedance()2-8
Preout Impedance()500
Preout Level(mV)/Load -Unbalanced5000mV/10k
FLAC DecodeFLAC file, up to 24bit/48kHz
WAV Decode-
AAC DecodeCompliant with MPEG2/4 AAC LC
WMA decodeCompliant with Windows Media Audio
MP3 decodeCompliant with MPEG-1 Audio Layer-3
Frequency Response20Hz - 20,000Hz
Maximum Supply currentDC5V 1.5A
Capacity32 GB max, 255 Folders max, 999 Files per Folder max
File SystemFAT16, FAT32, ExFAT
Compatible DevicesMass storage class
USBUSB 2.0 (Full speed)
Frequency Range(Frequency step)USA/Canada: 162.400MHz - 162.550MHz(25kHz)
Frequency Range(Frequency step)Australia: 531kHz - 1701kHz(9kHz)
Frequency Range(Frequency step)Middle East: 531kHz - 1602kHz(9kHz)
Frequency Range(Frequency step)Japan: 522kHz - 1629kHz(9kHz)
Frequency Range(Frequency step)Europe, Russia, Asia: 531kHz - 1611kHz(9kHz)
Frequency Range(Frequency step)North America, South America, : 530kHz - 1700kHz(10kHz)
Frequency Range(Frequency step)Japan: 76.0MHz - 99.0MHz(100kHz)
Frequency Range(Frequency step)North America: 87.9MHz - 107.9MHz(200kHz)
Frequency Range(Frequency step)South America, Europe, Russia, Asia, Middle East, Australia: 87.5MHz - 108MHz(50kHz)
Picture Size2.7 inch Color TFT
Water proofIP66 (Equivalent to IEC standard publication 60529 IP66) (IP66 Faceplate, IPX4 Body)
Net Weight(includes Trim Bezel, Mounting Plate, Screws)0.9(kg), 2.0(lbs)
(D)74(mm), 2-15/16(in)
(H)106(mm), 4-3/16(in) Panel 77(mm), 3-1/16(in) body
(W)115(mm), 4-9/16(in) Panel77(mm), 3-1/16(in) body
Operating voltage12V DC battery
Level-9dB to 9dB
Frequency62.5 / 100 / 160 / 250 / 400 / 630 / 1k / 1.6k / 2.5k / 4k / 6.3k / 10k / 16k Hz
Band13 Band
