While the RSA-500 subwoofer amplifier was primarily designed for use with the RW-5802 and RW-5101-C in-wall subwoofers, it also features custom settings for the AW-800-SW outdoor subwoofer.
Rack ears included
This high-powered device will drive up to two of any of these subwoofer modules and delivers 300 watts into an 8-ohm load (one subwoofer module) and 500 watts into a 4-ohm load (two subwoofer modules). It also comes with rack ears for fast and secure placement into any standard 19-inch rack.
To keep end users from inadvertently tampering with performance levels the majority of the RSA-500’s controls are housed on its rear panel. The fuse is also included on the back for quick and easy replacement. A detachable IEC power cord allows for the simple removal and reinstallation of the entire amplifier unit. The RSA-500 was also designed to “play nice” by offering standard input/output connectivity that will support any type of system.
|FREQUENCY RESPONSE:||20Hz-1kHz 3dB|
|AMPLIFIER POWER:||FTC Rated Power: 300W into 8 ohms, 500W into 4 ohms, 20Hz-1kHz @ <1.5% THD Dynamic Power: 875W into 8 ohms,|
|LOW PASS CROSSOVER:||Continuously variable from 40-120Hz,|
|ENCLOSURE TYPE:||Use only with RW-5802, and AW-800-SW subwoofer enclosures (either one or two)|
|INPUTS:||2 Gold-plated speaker binding posts, 2 Gold-plated RCA phono jacks plus single LFE|
|OUTPUTS:||2 Gold-plated unfiltered RCA phono jacks plus single LFE|
|AUTO POWER ON:||2 second ON delay, 15 minute OFF delay|
|DIMENSIONS:||3.5" (8.9cm) H x 17" (43.2cm) W x 12.6" (32cm) D (without rack ears)|
|WEIGHT:||18 lbs. (8.2kg)|
|FINISHES:||Black anodized aluminum face plate|
|FEATURES:||Selectable EQ, Speaker Level In, Low voltage trigger, rack ears included|
|PHASE:||Switchable between 0 and 180 degrees|
|VOLTAGE:||110/120 VAC 60Hz|
