Pioneer TS-WX140DA

Pioneer Built-in 170w Output Class-D Amplifier Compact Active Subwoofer - TS-WX140DA



Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.


Our Price $380.00 CAD
Availability
Schedule Delivery


  • Aluminum Cone Designed for Compact Body
  • Built-In 170 Watts Output Class-D Amplifier
  • Digital Bass Control (Selectable Bass Mode: Deep, Dynamic, or Natural)
  • Wired Remote Control (Gain, LPF, Phase, Bass Mode)

EV Optimized

The TS-WX140DA is the perfect addition for more bass in your electric vehicle With a built-in, high-efficiency 170-watt Class-D amplifier, the maximum current draw is only 4.3 amps max, so you don't have to worry about lower mileage due to your bass addition... and fun The specially designed honeycomb structure enclosure and Digital Bass Control (Pioneer technology), allows you to increase the performance, producing deep and powerful bass without the typical sacrifice in space.

Combines a built-in 170-watt Class D amplifier, aluminum cone specially designed acoustic suspension enclosure, and Digital Bass Control, a technology developed by Pioneer to tailor frequency response and increase the performance, is compact while producing deep, powerful bass.

Digital Bass Control now provides three selectable listening modes, Deep, Dynamic and Natural, enhancing system optimization and tuning the output to complement various musical styles and vehicle types.

Extremely compact, measuring 11 inches x 7-7/8 inches with a height of only 2-3/4 inches, and is designed to be installed in various sm all, tight spaces. With the ability to fit under seats, behind seats or inside small storage compartments, the features a wide range of vehicle applications. In addition to its compact size, the TS-WX140DA also incorporates a recessed section for connectors amp controls, and multi-angle mounting brackets adding to its installation flexibility.

What's in the Box Powered subwoofer 10.5" RCA input harness (4-pin Molex plug/2 female RCAs) Power harness with 16.5' power and remote turn-on leads and 6' ground wire (3-pin Molex plug) 10A ATO fuse in fuse holder (installed on power wire) Wired Digital Bass Control with attached 16.25' cable (RJ-45 plug) 2 Mounting feet Cable clamp 2 Self-tapping screws (M5 x 18mm) 2 Machine screws (M5 x 14mm) 2 Machine screws (M3 x 8mm) Adhesive backed hook-and-loop pad Instruction Manual Warranty sheet

Powerful Amplified Subwoofer

Combines a built-in 170-watt Class D amplifier, aluminum cone specially designed acoustic suspension enclosure, and Digital Bass Control, a technology developed by Pioneer to tailor frequency response and increase the performance, is compact while producing deep, powerful bass.

Digital Bass Control

Digital Bass Control now provides three selectable listening modes, Deep, Dynamic and Natural, enhancing system optimization and tuning the output to complement various musical styles and vehicle types.

Installation Flexibility

Extremely compact, measuring 11 inches x 7-7/8 inches with a height of only 2-3/4 inches, and is designed to be installed in various sm all, tight spaces. With the ability to fit under seats, behind seats or inside small storage compartments, the features a wide range of vehicle applications. In addition to its compact size, the TS-WX140DA also incorporates a recessed section for connectors amp controls, and multi-angle mounting brackets adding to its installation flexibility.

What's in the Box

What's in the Box Powered subwoofer 10.5" RCA input harness (4-pin Molex plug/2 female RCAs) Power harness with 16.5' power and remote turn-on leads and 6' ground wire (3-pin Molex plug) 10A ATO fuse in fuse holder (installed on power wire) Wired Digital Bass Control with attached 16.25' cable (RJ-45 plug) 2 Mounting feet Cable clamp 2 Self-tapping screws (M5 x 18mm) 2 Machine screws (M5 x 14mm) 2 Machine screws (M3 x 8mm) Adhesive backed hook-and-loop pad Instruction Manual Warranty sheet

Key Features
Sensitivity (1W/1m)DEEP: 95 dB / DYNAMIC: 100 dB / NATURAL 98 dB
System TypePowered
Subwoofer Design
DamperAramid
Voice Coil wireCopper
Voice Coil BobbinGlass imide
Voice Coil TypeSingle Voice
Magnet Weight17.2 oz
Magnet MaterialFerrite
Basket MaterialIron Plate Press
Surround TypeRolled
Surround MaterialUrethane
Drive Cone MaterialAluminum
ShapeOval
Size8" x 5-1/4"
Cone MaterialCellulose fiber
Key Features
Amp RMS Output50 Watts
Amp Max Power Output170 Watts
Built In AmpYes
Speaker GrillFully Covered Steel Mesh Grille
Frequency RangeDEEP: 20 Hz to 200 Hz / DYNAMIC: 40 Hz to 160 Hz / NATURAL 40 HZ to 200 Hz
Warranty1 Year
Continuous Power handling (RMS) - Watts50 Watts
Maximum Peak Power Handling - Watts170 Watts
