Pioneer TS-WX1220AH
Pioneer Dual Ported Enclosure Active Subwoofer with Built-in Amplifier - TS-WX1220AH

Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Our Price $1,000.00 CAD
Schedule Delivery


  • 3,000W Max. 1,000W Nom. Power (Sub)
  • 1,200W Max. 600W Nom. Power (Amp)
  • Variable Bass Boost (0 to 12 dB, 40Hz to 100Hz)
  • Dimensions: 29-3/8" x 18-1/8" x 15-3/4"
  • Remote Control Included

What’s in the Box

  • TS-WX1010LA Ported Active Enclosure Subwoofer
  • 4 Mounting Brackets
  • 2 (5 x14mm) screws
  • 8 (M5 x 25mm) screws
  • 1 Wired Remote Bass Controller Knob
  • 1 10.5" RCA input harness (4-pin Molex plug/2 female RCAs)
  • 2 40A ATO fuse in holder (installed on power wire)
  • 1 Allen Key Wrench Tool
  • Installation Manual
  • Warranty Sheet
Voice Coil wireCopper
Voice Coil BobbinKapton
Voice Coil TypeSingle Voice
Magnet Weight42.3oz
Magnet MaterialFerrite
Basket MaterialStamped Metal
Surround TypeRolled
Surround MaterialUrethane
Center Cap MaterialPP
Cone MaterialCellulose fiber
Key Features
Amp GroundingNegative
Amp Max Current Consumption50 A
Power SourceDc 14.4 V
Input Level (@ Gain Max) Speaker Line2 V+2 V/5 kOhm
Input Level (@ Gain Max) RCA100 mV+100 mV/22 kOhm
Amp RMS Output600 Watts
Amp Max Power Output1200 Watts
Built In AmpYes
Bass Boost Level0 to +12 dB
Warranty1 Year
CTA-2031 CompliantYes
Frequency Range20 Hz to 2.9 kHz
System TypePowered
Sensitivity (1W/1m)92 dB
Continuous Power handling (RMS) - Watts1000 Watts
Maximum Peak Power Handling - Watts3000 Watts
Speaker GrillFully Covered Steel Mesh Grille
Bass Boost Frequency40Hz to 100Hz
