Rockford Fosgate PMX-3

Rockford Fosgate Compact Digital Media Receiver - PMX-3



Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.


Price$829.99
Savings$130.00
Our Price $699.99 CAD
Sale Ends : April 30, 2025
On Sale
Buy Online
Availability
Schedule Delivery

Literature

The PMX-3 is a ground up designed digital media receiver for marine and motorsports applications with full color 2.7" TFT display. This unit not only has the functionality you desire such as a custom designed GUI interface and menu system built with "ease of use" in mind, but also features SiriusXM tuner compatibility, Pandora radio control via USB or Bluetooth and full iPhone support with folder browsing capability.

Overview

The PMX-3 compact digital media receiver, designed for marine and motorsports applications, features a 2.7"full color TFT display for optimum viewing even in full sun that is optically wet bonded to prevent any dust or moisture penetration. The PMX-3 is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such SiriusXM tuner compatibility, Pandora control capabilities and Bluetooth audio steaming with album art support1, this unit becomes a true command center of any system. Output flexibility comes with a 4x50 @ 2ohm internal amplifier or front and rear/sub output RCA's allowing the addition of aftermarket amplifiers for more power and output.   1Android devices equipped with limited functionality. Please refer to owners manual for details. We've also upgraded the unit to feature a reverse camera composite video input with reverse trigger control and a day/ night display mode for better viewing in low light conditions. Finally, add in the EEprom memory system, custom GUI interface and wired remote expansion capabilities and you have the only media receiver you'll ever need.

  • 2.7" Full color Thin Film Transistor display
  • SiriusXM-Ready™ (SXV300 module) with color channel logos (18 channel presets)
  • Electrically Erasable Programmable Read-Only Memory (EEPROM) is a type of non-volatile memory used in electronic devices to store data that must be saved when power is removed
  • Integrated voltage gauge w/ low voltage alert
  • Wired remote ready (up to 3 remotes)
  • Two-piece mounting system to secure panel to mounting surface
  • Front Panel Sub Control
  • Upgradeable Firmware and Bluetooth Software via USB
  • IPX6 Marine Grade for prevention of water intrusion
  • ASTM: B117 Salt Fog & D4329 UV Exposure Tested
  • Single Zone output with 2 channels front full range and 2 channels rear/ subwoofer selectable rated at 2 volt
  • Internal power amplifier 4x45W 2Ω stable
  • Automotive grade AM/FM Radio, Weatherband Radio digital tuner. Supports Radio Data System (RDS) to receive broadcast information
  • Licensed Pandora control (Apple direct USB or BT/Android via Bluetooth)
  • Made for iPhone apple certified
  • Bluetooth streaming audio (A2DP) protocol version 1.4 installed
  • Rear USB With 1A Charging Only
  • Rear AUX-In (L/R)
  • Simple Secure Pairing (SSP)
  • Display album art from connected iPhones on the radio display
  • Folder browsing via BT connected iPhones
  • Dedicated DSP audio processors for each zone with independent 7 Band EQ + Punch EQ
  • Selectable high pass and low pass crossover points for each zone
  • Selectable crossover slopes of 12dB or 24 dB for each zone
  • Adjustable input gain for each source
  • Waterproof Rotary Encoder Volume Control
  • Tactile convex buttons for easy identification
  • White LED Button Illumination
  • Wired and front panel illumination control
  • Wet Bonded Display
  • Epoxy coated circuit board for water resistance
  • External trigger input to activate reverse camera mode
  • Direct composite video input connection
  • Day/Night display mode
  • 2-Year Warranty

Technologies

SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Element Ready™ - Source Units

These source units are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

Built In Bluetooth®

Built In Bluetooth®

Pandora®

Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.

Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Made for Android

This device supports the Google "Made for Android" protocol.

USB Playback

This source unit supports playback from a USB device.

ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

IPX6 Water Intrusion Rating

IPX6 Water Intrusion Rating

FLAC

The Free Lossless Audio Codec is an audio format similar to MP3, but lossless, meaning that audio is compressed in FLAC without any loss in quality.

Specifications
FEATURES
Bluetooth® (Yes/No)Yes
3.0+EDR, A2DP 1.3
Pandora® Internet Radio (Yes/No)Yes
SiriusXM-Ready® (Yes/No)Yes
USB Charging (Yes/No)Yes
Apple®/Android™ Compatible (Yes/No)Yes
Limited functionality on Android. See owners manual.
Steering Wheel Control Ready(Yes/No)No
Multi-Zone/Multi-Source (Yes/No)No
Speaker Outputs (Yes/No)Yes
AUX Input (Yes/No)Yes (1pr)
Clock (Yes/No)No
TUNER
TUNER Number Of Presets18 FM / 12 AM / 6 WB
AM TUNER Frequency Range530 kHz - 1710 kHz
AM TUNER Usable Sensitivity40 dB
FM TUNER Frequency Range87.5 MHz - 107.9 MHz
FM TUNER Sensitivity8 dB
RCA Output Voltage2V RMS
Does not clip at full output
RCA OUTPUTS(1 pr) Front
(1 pr) Rear (or Sub-out)
RCA Output Impedance500Ω
RCA Output Impedance500Ω
SPEAKER OUTPUTS
Speaker Impedance2-Ohms
GENERAL
Device TypeDigital-Media Receiver
Frequency Response20 Hz - 20 kHz
MEDIA PLAYER Audio Format CompatibilityMP3
WMA
FLAC
AAC
DRM
Made for iPod ModelsiPod Touch (5th generation)
iPod Touch (4th generation)
iPod Nano (7th generation)
iPod Nano (6th generation)
Made for iPhone ModelsiPhone XS (pending)
iPhone XS Max
iPhone XR (pending)
iPhone X
iPhone 8
iPhone 8 Plus
iPhone 7
iPhone 7 Plus
iPhone 6s
iPhone 6s Plus
iPhone 6
iPhone 6 Plus
iPhone 5S
iPhone 5C
iPhone 5
iPhone 4
iPhone 4S
Phone 3GS
Android CompatibilityBluetooth® Only
USB Capacity32Gb max
999 Folders max
999 Songs max
USB Version2.0
USB Output Current1A
Compatible RemotesPMX-1R
PMX-0R
(3 Remote Limit, 100 ft Total Wired Distance)
Operating Voltage10.5 V - 16 V
Display Size2.7" Color TFT
Back Panel Cutout3" (77mm)
Fuse Rating20 A
Dimensions (HxWxD)Width 4.5" (11.5cm)
Face Depth 1.5" (3.8cm)
Mount Depth 2.9" (7.4cm)
Height 4.2" (10.6cm)
Shipping Weight3.1 Lbs. (1.41 Kg)
