Rockford Fosgate PMX-5CAN

Rockford Fosgate Punch Marine AM,FM,WB Digital Media Receiver with CAN bus - PMX-5CAN



Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.


Price$709.99
Savings$110.00
Our Price $599.99 CAD
Sale Ends : April 30, 2025
On Sale
Buy Online
Availability
Schedule Delivery

Literature

The PMX-5CAN is an AM/FM/WB tuner and digital media receiver with 2.7" full color display with CAN bus functionality.  Features CANbus functionality for connection to Raymarine MFD (Multi-Function Display) systems using PMX-CAN.

Overview

The PMX-5CAN digital media receiver is designed for marine and motorsports systems. The PMX-5CAN features a 2.7"full color TFT display for optimum viewing - even in full sun - that is optically wet bonded to prevent any dust or moisture penetration. It is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such as SiriusXM and Pandora capabilities, Bluetooth audio steaming with album art support for Apple and Android products and true 2 zone/2 source control, this unit becomes a true command center of any system. Output flexibility comes a 4x50W @ 2ohm internal amplifier or dual zone output RCA's allowing the addition of after-market amplifiers for more power and output. Add in the EEPROM memory system, custom GUI interface and wired remote expansion capabilities and you have the only media receiver you'll ever need. The PMX-5CAN also features CANbus functionality for connection to Raymarine MFD (Multi-Function Display) systems using the PMX-CAN adaptor (see Accessories tab.)

  • ISO8846/SAE J1171 Ignition Protection Certified
  • Stainless Steel Rear Chassis
  • Steering Wheel Control Interface Compatible
  • Pandora Internet Radio
  • SiriusXM-Ready™
  • A2DP and AVRCP Bluetooth Wireless Streaming
  • FCC, CE, IC, and C-Tick Certified
  • Multi Region Radio Frequencies
  • Low Voltage Warning Alert
  • AUX and USB Inputs with USB Charging
  • On Board Punch EQ Control
  • Independent Subwoofer Level Control
  • Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
  • IPX6 Marine Grade for prevention of water intrusion
  • 7-Band Graphic EQ
  • 2.7" full color display w/ auto dimming backlightning
  • Zone Control: 2 Zone / 2 Source (F/R/S + F)
  • AM / FM / WB Tuner
  • CANbus (Controller Area Network) compatible. Requires PMX-CAN accessory
  • Compatible with a Multi-Funtion Display using NMEA2K entertainment standard. See our MFD Compatibility Chart
  • *Antenna not included
  • 2-Year Warranty

Technologies

Element Ready™ - Source Units

These source units are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Pandora®

Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.

Built In Bluetooth®

Built In Bluetooth®

Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Made for Android

This device supports the Google "Made for Android" protocol.

USB Playback

This source unit supports playback from a USB device.

ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

IPX6 Water Intrusion Rating

IPX6 Water Intrusion Rating

CANbus

CANbus allows communication with other devices.

FLAC

The Free Lossless Audio Codec is an audio format similar to MP3, but lossless, meaning that audio is compressed in FLAC without any loss in quality.

Specifications
FM TUNER Frequency Range87.9-107.9 MHz
FM TUNER Sensitivity8 dB
AM TUNER Usable Sensitivity40 dB
RCA Output Voltage4V
Operating Voltage10.5 V - 16 V
Fuse Rating15 A
MEDIA PLAYER Audio Format CompatibilityMP3
WMA
FLAC
AAC
DRM
TUNERN/A
Speaker Outputs (Yes/No)Yes
Made for iPod ModelsiPod Touch (5th generation)
iPod Touch (4th generation)
iPod Nano (7th generation)
iPod Nano (6th generation)
Android CompatibilityBluetooth® Only
RCA OUTPUTSN/A
Device TypeDigital-Media Receiver
SiriusXM-Ready® (Yes/No)Yes
Requires SXV300
Pandora® Internet Radio (Yes/No)Yes
RCA Frequency Response87.5 MHz - 107.9 MHz
WB TUNER Frequency Range162.40 - 162.55
(US & Canada)
TUNER Number Of Presets18 FM / 12 AM / 6 WB
USB Output Current1A
USB Charging (Yes/No)Yes
Frequency Response20 Hz - 20 kHz
Made for iPhone ModelsiPhone XS (pending)
iPhone XS Max
iPhone XR (pending)
iPhone X
iPhone 8
iPhone 8 Plus
iPhone 7
iPhone 7 Plus
iPhone 6s
iPhone 6s Plus
iPhone 6
iPhone 6 Plus
iPhone 5S
iPhone 5C
iPhone 5
iPhone 4
iPhone 4S
Phone 3GS
Apple®/Android™ Compatible (Yes/No)Yes
AM TUNER Frequency Range530 kHz - 1710 kHz
RCA Output Impedance500Ω
Speaker Impedance2-Ohms
Dimensions (HxWxD)Width 8" (20.3cm)
Face Depth 1.5" (3.8cm)
Mount Depth 7.1" (18.2cm)
Height 3.5" (8.9cm)
Chassis to Face Top 0.9" (2.3cm)
Chassis to Face Bottom 0.59" (1.5cm)
USB Capacity32Gb max
999 Folders max
999 Songs max
Clock (Yes/No)No
Display Size2.7" Color TFT
Bluetooth® (Yes/No)Yes
3.0+EDR, A2DP 1.3
USB Version2.0
Steering Wheel Control Ready(Yes/No)Yes
Multi-Zone/Multi-Source (Yes/No)Yes
Compatible RemotesPMX-1R
PMX-0R
(3 Remote Limit, 100 ft Total Wired Distance)
AUX Input (Yes/No)Yes
FEATURESN/A
