FiiO Q11

FiiO Portable DAC and Headphone Amplifier - Q11



Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.


Availability
Schedule Delivery


Portable DAC and Headphone Amplifier

High-performance CS43198 DAC | Supports 384kHz/32bit PCM 650mW power output | Ambient light design | 3.5+4.4mm outputs Supports DSD256 | 2600mAh battery capacity | High+Low gain levels





Listening to true HiFi on a phone

Not a problem

Are you feeling anxious under the condition that more and more phones lose the headphone jack, more and more streaming services offer lossless audio, and dongles are hungry for power supply? Every issue will be perfectly solved with the Q11. It offers no compromises thanks to its high performance and longer battery life (for itself and your phone), providing you with a HiFi music experience.



Truly-moving sound Thanks to internal magic

The Q11 is truly "Born For Music" thanks to the carefully-selected components integrated into a well-thought-out design, all in a meticulously-tuned package.



With form and function Superb sound and shape

The compact body of the Q11 is specifically designed so that the Q11 can be bundled together and used with the vast majority of phones. The straight and smooth edges of the Q11 make it a joy to use in the hands, while the elegant black finish combined with the gold label accents makes the Q11 an eye-catching device.



Powerful portable Sound with personality

With a balanced power output of up to 650mW, as well as low and high gain levels, it is easy to listen to both low and high-impedance headphones on the Q11 anytime, anywhere.



Great parts and great sound

Have it all

Thanks to the high-performance CS43198 DAC, dual op-amps, high-precision crystals and low-noise power supply, the Q11 is highly resolving and dynamic for a more immersive listening experience.

PCM: 384kHz/32bit; DSD256(/strong>



Long battery life For a true piece of mind

Whether it's on the work commute or weekend travels, you can be sure that you will be able to listen to the Q11 all day thanks to its large battery.



Ambient light window

Your ticket to the HiFi world

The ambient light window not only dazzles you with lights that indicate the current sampling rate or DSD format, but also allows you to elegantly peer at the internals currently giving you your music.

* The Q11 can be controlled by the FiiO Control app, with settings of ambient light on/off, filter selections, etc.



Common outputs For the everyday listener

The 3.5mm SE and 4.4mm balanced outputs are clearly outlined by a golden ring, allowing for more versatility and better sound quality for music on the go.

* The 3.5mm headphone output also supports coaxial output.



Supports UAC1.0

Connect to Switch, PS5 and other devices

The Q11 supports UAC1.0 and UAC2.0 modes*. In the UAC 1.0 mode, the Q11 can be connected to devices like the Switch/PS5, allowing you to get into a gaming world that makes your gaming sessions more exciting and immersive.

* Please switch the UAC1.0 and UAC2.0 modes in the FiiO Control APP.



Two-in-one knob

An elegant fusion

The silky and perfectly weighted feel of the volume knob allows you to precisely dial in your desired volume. It also conveniently acts as an on/off switch.



A wide variety of musical landscapes





Audio parameters
Headphone output performance parameters (3.5mm) - Noise floor1.8uV"A"
Headphone output performance parameters (3.5mm) - SNR≥ 122dB (32Ω A weighted)
Headphone output performance parameters (3.5mm) - Crosstalk≥70dB(1Khz,32Ω)
Headphone output performance parameters (3.5mm) - Output impedance< 1.2Ω
Headphone output performance parameters (3.5mm) - Output amplitude≥2.3V(32Ω,THD+N<1%), ≥ 2.4V (no-load)
Headphone output performance parameters (3.5mm) - THD+N< 0.0006% (-3dB, 32Ω )
Headphone output performance parameters (3.5mm) - Frequency response20Hz~ 20Khz, curve amplitude change ≤ 0.1dB, 20Hz~ 50Khz, curve amplitude change ≤ 0.1dB
Headphone output performance parameters (3.5mm) - Output power310mW(16Ω,THD+N<1%.USB IN), 165mW(32Ω,THD+N<1%,USB IN), 19mW(300Ω,THD+N<1%,USB IN)
Buttons and interfaces
Battery life and test conditions - Impedance32ohms
Battery life and test conditions - Output power40mV
Battery life and test conditions - Music trackMP3 44.1K-16bit
Battery life and test conditions - Audio inUSB
Power parameters - Charging time<2.5H
Power parameters - Battery lifePO≥13.5H BAL≥13H
Power parameters - Battery capacity2600mAH
Power parameters - Power supplyDC5V 2A (recommended)
BAL phone outStandard 4.4mm port
SPDIF output3.5mm port (shared with PO)
SE phone outStandard 3.5mm port
Light holePower indicator
Toggle SwitchGain switch
Ambient light windowSampling rate indicator
USB interfaceTYPE-C USB2.0 (charging/data)
KnobSwitch/Volume Adjustment
Specifications
Maximum supported sampling rate384kHz/32bit (USB, COAX), DSD64/128/256
Recommended headphone impedancePO: 16 ~ 150Ω, BAL: 16 ~ 300Ω
SizeAbout 60.5 * 105.7 * 16mm
Hardware solutionsDAC:CS43198
Volume controlAnalog Potentiometer (ADC Sampling)
Name/ModelQ11
ColorBlack
Weight≈150g(main machine)
Sampling rate indicatorLight blue: ≤48K, Yellow: >48K, Green: DSD
Audio parameters
Headphone output part performance parameters (4.4mm) - Noise floor2.4uV"A"
Headphone output part performance parameters (4.4mm) - SNR≥ 125dB (32Ω A weighted)
Headphone output part performance parameters (4.4mm) - Crosstalk≥102dB(1Khz,32Ω)
Headphone output part performance parameters (4.4mm) - Output impedance< 2.0Ω
Headphone output part performance parameters (4.4mm) - Output amplitude≥4.5V(32Ω,THD+N<1%), ≥ 4.8V (no-load)
Headphone output part performance parameters (4.4mm) - THD+N< 0.0006% (-6dB, 32Ω )
Headphone output part performance parameters (4.4mm) - Frequency response20Hz~ 20Khz, curve amplitude change ≤ 0.1dB, 20Hz~ 50Khz, curve amplitude change ≤ 0.1dB
Headphone output part performance parameters (4.4mm) - Output power640mW(16Ω,THD+N<1%.USB IN), 650mW(32Ω,THD+N<1%,USB IN), 75mW(300Ω,THD+N<1%,USB IN)
