Ortofon 2M Black

Ortofon 2M Black Moving Magnet Cartridge - 2M Black

Ortofon 2M Black

Ortofon 2M Black Moving Magnet Cartridge - 2M Black



Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.


Our Price $938.00 CAD
Our Price $938.00 CAD
Buy Online
Availability
Schedule Delivery

Buy Online
Availability
Schedule Delivery

Literature

2M Black Technical data

  • Output voltage at 1000 Hz, 5cm/sec.  -  5 mV
  • Channel balance at 1 kHz  -  1 dB
  • Channel separation at 1 kHz  -  26 dB
  • Channel separation at 15 kHz  -  15 dB
  • Frequency range at - 3dB  -  20-31.000 Hz
  • Frequency response  -  20-20.000 + 2 / - 0 dB
  • Tracking ability at 315Hz at recommended tracking force  -  80 µm
  • Compliance, dynamic, lateral  -  22 µm/mN
  • Stylus type  -  Nude Shibata
  • Stylus tip radius  -  r/R 6/50 µm
  • Tracking force range  -  1.4-1.7 g (14-17 mN)
  • Tracking force, recommended  - 1.5 g (15 mN)
  • Tracking angle  -  20°
  • Internal impedance, DC resistance  -  1.2 kOhm
  • Internal inductance  -  630 mH
  • Recommended load resistance  -  47 kOhm
  • Recommended load capacitance  -  150-300 pF
  • Cartridge colour, body/stylus  -  Black/Black
  • Cartridge weight  -  7.2 g
  • 2M PnP MkII cartridge with integrated headshell weight  -  20 g
  • 2M PnP MkII cartridge with integrated headshell length - 52 mm
  • Replacement stylus unit  -  2M Black (interchangeable with 2M Bronze)

Stylus lifetime: with proper care we find that up to 1000 hours is possible without degradation of performance.

The 2M Black Series is the MM flagship from Ortofon

The 2M Black is graced with a Shibata diamond which slim, highly polished profile allows an exceedingly wide contact area to the groove walls and ensures notably detailed reproduction throughout the spectrum, including even the most high frequency groove information.

The cartridge body is manufactured from Hopelex, an environment-friendly material which ensures high rigidity while eliminating unwanted resonances.

 The 2M Black uses a special upgraded engine, featuring split pole pins with a silver plated copper wire.

We have optimized the design for ease of mounting the cartridge, and the weight and size to fit the most common turntables on the market today. The 2M Series provides excellent compatibility when used in an assortment of playback systems and with a wide variety of phono preamps.

Specifications
Output voltage at 1 kHz, 5 cm/sec.5 mV
Frequency range at -3 dB 20–31,000 Hz
Tracking ability at 315 Hz at recommended tracking force80 µm
Compliance, dynamic, lateral22 µm/mN
Stylus type Nude Shibata
Tracking force recommended*1.5 g (15 mN)
Load resistance*47 kOhm
Load capacitance*150–300 pF
