Pioneer 10" Z-Series Single 2 Ohms Voice Coil Subwoofer - TS-Z10LS2
WAS $600.00
$499.99
OR
$125.00
In 4 installments with
Sale Ends : September 30, 2027
On Sale
Literature
You may also like
WAS
$240.00
$219.99
WAS
$240.00
$219.99
WAS
$200.00
$169.99
WAS
$260.00
$249.99
- Twaron Aramid Fiber Cellulose Fiber Dual Layer Cone Construction
- Extended Voice Coil, Dual Spider Design for Increased Linearity and High Excursion
- Shallow Basket, Small Enclosure Design for Sound Optimization and Installation Flexibility
- Designed for Hi-Res Audio
| Build | |
|---|---|
| Port Diameter | 3" |
| Port Length | 7-1/2" |
| Port Box volume [L] | 17 |
| Recommended Sealed Box Volume [L] | 17 |
| Linear Excursion (Xmax) [mm] | 9.4 |
| Total Speaker "Q" (Qts) | 0.48 |
| Free Air Resonance (Fs) [Hz] | 34 |
| Equivalent Compliance (VAS) [L] | 23.1 |
| Cut Out dimensions | 9-1/8" |
| Mounting Depth | 3-1/4" |
| Unit Size (Dimensions) | 11-1/8" |
| Wire Terminals | Push Type |
| Gasket | Rubber |
| Damper | Poly cotton |
| Voice Coil wire | Copper |
| Voice Coil Bobbin | Glass imide |
| Voice Coil Type | Single Voice |
| Magnet Weight | 70.2 oz |
| Magnet Material | Ferrite |
| Basket Material | Die Cast Aluminum |
| Surround Type | Rolled |
| Surround Material | Rubber |
| Drive Cone Material | Twaron Aramid Fiber |
| Cone Material | IMPP - Composite |
| Shape | Round |
| Size | 10" oversized |
| Key Features | |
| Maximum Peak Power Handling - Watts | 1300 Watts |
| Nominal Impedance - OHM | 2 |
| Continuous Power handling (RMS) - Watts | 400 Watts |
| Warranty | 1 Year |
| CTA-2031 Compliant | Yes |
| Hi-Res Certified | Yes |
| Frequency Range | 20 Hz to 3.8 kHz |
| System Type | Component Subwoofer |
| Sensitivity (1W/1m) | 74 dB |
