Audio Technica AT-XP3/H

Audio Technica Headshell/Cartridge Combo Kit - AT-XP3/H

Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Our Price $119.00 CAD
Sale Ends : April 30, 2025
On Sale
Schedule Delivery

The AT-XP3/H combo kit includes the AT-XP3 DJ cartridge premounted on the AT-HS6BK headshell.


  • 0.6 mil conical bonded stylus tip
  • Highly-rigid polyphenylene sulfide (PPS)/glass fiber body
  • 5.5 mV high-level output
  • Tracking force of 2.0 to 4.0 grams (3.0 grams standard)
  • Durable carbon fiber-reinforced ABS cantilever and nylon wire suspension ensure precise tracking
  • Design offers maximum visibility of the stylus tip
  • Great tracking and channel separation for high-fidelity sound
  • AT-XP3 cartridge is compatible with any XP or VM95 Series replacement stylus, offering a wide choice of options for every budget and application
  • Universal ½"-mount headshell for 4-pin turntable cartridges
Weight cartridge 6.2 g (0.22 oz); cartridge and headshell 15.6 g (0.55 oz)
Stylus Size 0.6 mil
Replacement StylusATN-XP3
Recommended Load Capacitance100 to 200 pF
Mounting FeatureHalf-inch mount
Accessories IncludedTwo 11 mm installation screws, two 8 mm installation screws, two washers, two nuts, non-magnetic screwdriver
Dimensionscartridge 17.2 mm (0.68") H × 17.8 mm (0.67") W × 28.3 mm (1.20") D; cartridge and headshell 21.2 mm (0.83") H × 21.4 mm (0.84") W × 62.4 mm (2.46") D
Cartridge Weight15.6g
Dynamic Compliance6.0 x 10 – 6 cm / dyne (100 Hz)
Static Compliance20 x 10 – 6 cm / dyne
CantileverCarbon fiber-reinforced ABS
Stylus Shape0.6 mil conical
Output Channel Balance2.0 dB (1 kHz)
Output Voltage5.5 mV (1 kHz, 5 cm/sec.)
Coil Inductance550 mH (1 kHz)
Coil Impedance6.7 k ohms (1 kHz)
Recommended Load Impedance47,000 ohms
Stylus ConstructionBonded round shank
Vertical Tracking Force 2.0-4.0 g (3.0 g standard)
Vertical Tracking Angle 20°
Channel Separation20 (dB at 1 kHz)
Frequency Response20-18,000 Hz
