Rockford Fosgate R2-750X1

Rockford Fosgate Prime 750 Watt Mono Amplifier - R2-750X1



Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.


Price$629.99
Savings$230.99
Our Price $399.00 CAD
Sale Ends : January 06, 2025
On Sale
Buy Online
Availability
Schedule Delivery

Literature

Primed for Performance, the R2-750X1 amplifier is a 750 watt, class-D, capable of operating at 4Ω, 2Ω or 1Ω mono. This amplifier is extremely efficient because of its class D technology which reduces demand on the vehicles electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases, and integrated Punch EQ that corrects for acoustic deficiencies while delivering up to 3X the bass. For subwoofers, a variable infrasonic filter and remote level control allows you to tune the bass for the desired level for the music. R2 Amplifier Product Overview

Overview

The Prime Series were developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. The latest generation of Prime Series amplifiers are also designed to be easy to setup and configure, making them perfect for use with factory audio or custom aftermarket systems.

  • Balanced Differential Inputs with RCA Pass Through Outputs
  • High Level Input Capable
  • Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • Features C.L.E.A.N. Set-up
  • Variable Input Gain adjustment level
  • Includes RLC Remote Level Control
  • Variable Infrasonic Filter
  • Continuously Variable On Board Punch EQ
  • Top Mounted Control Panel
  • Short Circuit & Over Current Protection
  • CEA-2006 Compliant & CE Compliant
  • Cast aluminum heat sink
  • Full Range Class D
  • Rollback Protection
  • Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
  • 1 Year Warranty

Technologies

CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.

Class-D

High efficiency amplifier design that reduces current consumption from the charging system.

P.O.W.E.R.

Power supply circuit design that allows the amplifier to increase output power as voltage increases.

C.L.E.A.N. Set-Up

C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is a patented circuit with in/out clip LEDs to help match a source to amp and optimize output.

Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

MEHSA 4 (Maximum Efficiency Heat Sink Application)

MEHSA4 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.

Rollback Protection

During demanding musical conditions, the amplifier can dynamically reduce demand to prevent stress on the output devices.

CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 EC).

Specifications
Number of Channels1
Total Power (Sum of Rated Power)750 Watts
Rated Power (RMS Continuous Power)250 Watts x 1 @ 4Ω
500 Watts x 1 @ 2Ω
750 Watts x 1 @ 1Ω
Dynamic Power (PVC/PowerCube®)300 Watts x 1 @ 4Ω
545 Watts x 1 @ 2Ω
830 Watts x 1 @ 1Ω
BridgeableNo
Frequency Response20 Hz - 250 Hz
Input SensitivityLow-Level: 150 mV - 4 V
High-Level: 450 mV - 12 V
Circuit Topology ClassClass D
Total Harmonic Distortion (THD+Noise)4Ω: <1.0%
2Ω: <1.0%
1Ω: <1.0%
Signal InputLow-Level: 2 RCA
High-Level: 4-Pin Molex
Signal OutputLow-Level: 2 RCA
(Pass-Thru active with RCA or Hi-Level input)
Tone Controls0 to +18 dB @ 45 Hz
Crossover ControlsLow-Pass:
50 Hz - 250 Hz @ 12dB/Octave Butterworth
Infrasonic:
15 Hz - 40 Hz @ 12dB/Octave Butterworth
Remote ControlsYes
Visual IndicatorsPower/Protect
C.L.E.A.N. In
C.L.E.A.N. Out
Power Wire Gauge4 AWG
Power Input ConnectorCompression Terminal Block
Speaker Wire Gauge8 AWG
Speaker Output ConnectorCompression Terminal Block
CoolingConvection
Operating Voltage9 - 16 VDC
Recommended Fuse (not included)120 A
Max. Current Draw (13.8V Sinewave)71 A
Dimensions (H x W x D)1.9" x 6.8" x 10.1"
(4.9 cm x 17.3 cm x 25.5 cm)
